Specifications
| Inner conductor size: | 2 x 0.22 mm² (22 AWG) |
| Strands x conductor: | 7 x 0.20 Bare Copper (BC) |
| Insulation: | PE (Polyethylene) Ø 1.45 mm |
| Shielding: | Bare copper 0.22 drain wire (7 x 0.20) + 100% Conductive PVC |
| Outer jacket: | PVC Polyvinyl Chloride - Hardness grade: 65 Shore |
| Overall diameter: | 6.00 mm |
| Weight: | 39.5 Kg (87.78 lbs) per 1000 m (3280 ft) |
Mechanical / Electric Characteristics
| Conductor resistance at 20°: | <52 Ohm/Km |
| Conductor/conductor capacitance: | 60Pf/m |
| Insulation resistance at 20°: | >5000 Mohm/Km |
| Working temperature: | -30° / +70° |
| Color: | Blue |
